17-Stage Booster Pump 3HP 208-240/480VAC 3PH

(0)No Reviews yet
$1,818.74
SKU: P-WAT-2725

This booster pump could be used in the backroom of the wash site. It is used to increase the water pressure on applications in the wash tunnel. The booster pump has 17 stages and is a 3-horsepower pump with three phases. It has a max pressure rating of 225 PSI and utilizes 1" NPT inlet and outlet connections. It is designed to be used with clear water and can be mounted horizontally or vertically with the inlet down. The housing material is made of stainless steel while the impeller is made of noryl plastic material.

  • # of Stages: 17
  • Horsepower Rating: 3 HP
  • # of Phases: 3-Phase
  • Voltage Rating: 208-240/480 VAC
  • Frequency: 60 Hz
  • Max Pressure Rating: 225 PSI
  • Flow Rate: 34.1 GPM at 60 PSI, 16.6 GPM at 200 PSI
  • Inlet/Outlet Connection Size: 1" NPT
  • Max Liquid Temperature: 140F
  • Housing Material: Stainless Steel
  • Impeller Material: Noryl Plastic
  • Boosts Car Wash Water Pressure
  • Stainless Steel Housing for Superior Corrosion Resistance
  • Open Dripproof Motor Enclosure
  • Horizontally pr Vertically Mounted with Inlet Down
  • Capacitor- Start Motor Tyle
  • Ball Bearing
  • Continuous Duty
  • Clear Water Only
  • Manual Priming
