1/2" FNPT Polypropylene Check Valve

(0)No Reviews yet
$8.99
SKU: P-CHE-2015

This check valve is used in multiple applications of the wash site including the Drying Agent and Clear Coat Curved Hanging Rinse arches, Tommy Water Treatment Center, etc. This check valve is 1/2" Female NPT connections on both ends and is made of polypropylene material with Viton seals and stainless steel spring. It helps maintain proper flow direction, volume, and pressure levels. This valve has a 125 PSI max pressure rating and 1/3 PSI cracking pressure rating.

  • Ends: 1/2" Female NPT on Both Ends
  • Max Pressure: 125 PSI
  • Cracking Pressure: 1/3 PSI
  • Max Operating Temp: 140F
  • Body Material: Polypropylene
  • Spring Material: Stainless Steel
  • Seal Material: Viton
  • Dimensions: 2-1/2" X 1-1/2"
