Two Sensor Dual Display EC/TDS Meter

(0)No Reviews yet
$148.40
SKU: P-WAT-2416
This is used on the RO unit. The HM Digital PSC-64D EC/TDS Monitor reads in an extended range to monitor TDS levels for high output commercial systems. The PSC-64D offers dual display monitoring for the industrial water treatment professional. This extended range EC/TDS “mini” monitor continuously monitors 2 lines while sending out a 4-20mA output. If the TDS level rises above the user-set level, an alarm will sound and the unit will open or close a circuit via dry contacts to control a pump, solenoid valve or other external device. This monitor is used in water treatment applications, drinking water applications, and food and beverage applications.
  • Output Signal: 4-20mA
  • Range: 0-9999 ppm (mg/L); 0-10.0 ppt (g/L) EC: 0-9999 µS; 0-20.00 mS
  • Accuracy: 2%
  • Resolution: 0-99.99: 0.1 ppm/µS; 100-9999: 1 ppm/µS; 0.1 ppt/mS
  • Calibration: Digital to Any Point
  • Set Point: On-Screen Buttons
  • Probes: 1/2" Female NPT with 3' Cable
  • Power Source: AC 110V/220V
  • "Mini" Monitor. The HM Digital PSC-64D features a mini display which continuously monitors 2 lines while sending out a 4-20mA output.
  • Extended Range for Monitoring EC/TDS. The HM Digital PSC-64D features an extended range to monitor both TDS and EC.
  • Power Cord Included. The HM Digital PSC-64D features a power cord and other necessary parts that are included at no extra charge.
