7 Port Air Operated Detergent Dispenser Wall Mounted 120V

(0)No Reviews yet
$7,263.60
SKU: P-HFI-271-K

Wall mounted chemical dispensing system designed to deliver precise chemicals/detergents to tunnel/conveyor car wash equipment applications simultaneously. This dispensing system has 7 detergent functions and 9 air functions, is pre-wired, and plumbed for water, air, and chemical control. Injectors and versadial devices are sold separately. The system is designed for precision and efficiency, dispensing consistent and accurate mixed solutions, improving chemical performance while using less water, taking up less space, and requiring less maintenance during an operational lifespan of minimum 700,000 wash cycles. Included with the dispensing system are two PC3 to PC2 Adaptors.

  • Voltage Rating: 120 VAC
  • Operating Water Pressure: 200 PSI
  • Maximum Water Source Temperature: 140F
  • Water Filtration: 50 Micron
  • Air Inlet Line: 3/8” OD Polyflow per MD Panel
  • Air Outline Line: 3/8” OD Polyflow per Application
  • Air Inlet Pressure: 60-120 PSI Dry Air
